Elastic Rail Clip

Elastic rail clips, are mainly used to fix steel rail and rail tie plate or rail shoulder on the sleeper.
Our rail clips have many advantages, such as high-precision design, high tensile strength and corrosion resistance.
RK rail can supply the E type rail clip,PR type rail clip,Fast clip, SKL tension clip,Deenik clip, Guage lock clip, Nabla clip, Fist clip,Elastic plate,etc.

1. E type rail clip
We offer various elastic rail clip with size of steel bar diameter from 16mm to 20mm. We manufacture different types of elastic rail clips with flat toe for broad gauge line, having the toe load from 850kgf to 1100kgf, and are capable of providing any type of toe load and axle load to fix the rails on wooden, steel or concrete sleeper.
The normal type of E type rail clip we supply are E1609 rail clip,E1809 rail clip,E1804 rail clip,E1806 rail clip,E1813 rail clip,E2006 rail clip,E2007 rail clip,E2009 rail clip,E2039 rail clip,E2055 rail clip,E2056 rail clip,E2063 Rail Clip,E2091 Rail Clip

2. PR type rail clip
PR series rail clip is usually used on steel sleeper and wooden sleeper ,It is used with tie plate to fasten the rails.
The normal type of PR type rail clip we usually supply are PR85 Rail Clip,PR309 Rail Clip,PR401 Rail Clip,PR415 Rail Clip,PR601 Rail Clip.

3. Fast clip
Fast clip is usually used on concrete sleeper and wood sleeper , which is used with other rail accessories to fix rails. Widely used in South American countries.

The fast clip is designed with a captive system. Sleeper manufacturers shall assemble the components on the sleeper before delivery. This product is specially offered for the mechanized track renewals requiring automated clipping machines or hand tools. The clip for the system is manufactured in the shape of M, driven at right angles to the rail. Specially provided for 26tons axle load, the fast clip can be produced for heavy haul rail with the axle load up to 40tons .

4. SKL tension clip
Our 4.SKL tension clip is a boltable clip with high permanent clip strength.This rail clip is especially applied in rail construction with concrete sleepers with the diameter 13mm to 15mm, range from SKL1, SKL2, SKL3, SKL12, SKL14,SKL21, SKL30, etc.

5. Deenik clip
The Deenik clip is widely used in South America. The invention of rail clips revolutionized the speed of the railway transportation. As the manufacturer of rail clips, we are proud of our high quality products and good after-sale service, which have been appraised by many clients.

6. Guage lock clip
Guage lock clips are usually used on wooden sleeper and used with screw spike to secure rails.It is widely used in South American countries. The normal type is 6.Guage lock clip GL1419.

7. Nabla clip
Nabla clip is widely used in some countries in North Africa. It is also used on concrete sleepers, together with the double end screw spike and insulator.Nabla clip has excellent elastic property, with load 2500DaN.

8. Fist clip
Fist clip is a special spring clip ,which is used on concrete sleeper, with the insulation pin and plastic base plate for fixed rails, widely used in African countries.

9. Elastic plate
The Elastic plates are widely used in Mexico and other European countries in different design,which is also used on concrete sleeper,together with some accessories such as rail screw and Insulatorto fix the rails.
